Single-Phase: 5KVA

The 5 kVA (5000 VA) variant is the ultimate “Whole Home” or “Heavy Industrial” single-phase stabilizer. It is designed for users who need to protect multiple high-load appliances at once, such as a large Inverter AC, a water pump, and a complete home theater system simultaneously.

Technical Specifications

Capacity: 5000 VA / 5 kVA.
Model Number: TE-5000 L.
Control System: Advanced Microprocessor-based DC Servo Motor. This provides lightning-fast response times to voltage fluctuations.
Winding Type: Heavy-Duty 100% Pure Copper. Built with a larger core to handle sustained high-amperage loads without heat fatigue.
Efficiency: ±> 98.5\ (Extremely energy efficient).

Voltage Performance

Input Range: Standard Wide Range (130V – 260V AC) or Ultra Wide (90V – 260V) depending on specific winding.
Output Stability: Rock-solid 220V AC ± 1%.
Phase: Single Phase.
Frequency: 50Hz / 60Hz compatible.

Ideal Load Applications

The 5 kVA unit is a “workhorse” capable of running:

Air Conditioners: Easily handles a 2-ton or 1.5-ton AC with plenty of room for other appliances.
Whole Small Office: Powers 5-8 computers, a large photostat machine, and LED lighting.
Water Pumps: Handles the high startup current (inrush current) of 1HP or 1.5HP motors.
Main Line Protection: Often used at the main power entry point for small apartments to protect all internal outlets.

Key Features & Protection

Dual Digital Interface: Large, bright LED displays for real-time monitoring of Input and Output volts.
Heavy Duty MCB: Equipped with a high-ampere Miniature Circuit Breaker for superior overload and short-circuit protection.
Cooling System: Often includes an internal heat-sync or ventilated chassis design to maintain optimal performance during peak summer heat.
Time Delay Relay: Protects AC compressors by delaying power for a few minutes after a blackout.
